FANTINI COSMI - VM063

Sensible element made in stainless steel, laser welded. Cover in shockproof thermoplastic material. Output connections in shockproof and self-extinguishing thermoplastic V0 cable gland. Maximum temperature of the controlled fluid: 120°C. Pressure switch max body temperature: -35 ÷ 80°C. Storage and transport temperature: -35 ÷ 80°C. Unit weight: 0. 15 Kg. Electric featuresMicroswitch with manual reset and contacts in silver alloy. Contact rating according to EN 60730-1: 15(6)A 250V~ 50HzRating according to EN 60947-5-1Nominal insulation tension Ui 380V~Continuous duty nominal current Ith 15AOperating nominal current Ie: 220V- 250V~ 380V~Resistive load AC-12 – 15A 10AInductive load AC-15 – 2,5A 1,5AContinuous current DC-13 0,2A – –
