Coupled with the most common valves from DN15 to DN100 and from G1“to G2”, for the ZC (Fantini Cosmi) series up to DN150. Single-phase synchronous motor with bidirectional rotation. Bottom and device bracket in die-cast aluminum. Cover and indicator made of thermoplastic material. Angle of rotation equal to 90°. Possibility of manual operation. Adjustable height of the bracket, max 30mm. Possibility to add an auxiliary microswitch for pump control, signaling etc. (optional). Rotation torque: 15Nm. Insulation class: I. Screw terminals. Fitting for smooth pipes and for spiral ducts Pg 13. 5. Reversible plate. Electric featuresPower supply: 230Vca 50Hz. Power consumption: 4W. Contacts rating: 6(2)A 250Vca (micro aux).
