Direction of rotation selectable by wiringManual operation: button and handleStrength: min. 10 Nm (at nominal voltage)Rotation angle electronically limited to 90 °280 sec rotation timeSound level max 35 db (A)Reversible scale position indication 0 ÷ 1Mounting position all except engine belowProtection class IIAmbient temperature 0 ÷ 50 ° CStorage temperature -10 ÷ 80 ° CWeight 500 gProtection degree IP40Electric featuresRated voltage AC 230V 50 / 60Hz. Sizing 3. 5VA. Power consumption 3. 5W. Connection with screw terminals.
