Operating limit ±10% COILS ca. -5% ÷ +10% COILS cc. Closing time 10 msec. Brass-forged valve body. Internal parts in stainless steel (17% CR). Gaskets in VITON (fluoroelastomer). Temperature of the controlled fluid: -10 ÷140°C. With coil in d. c. the indicated pressure should be reduced by 60%. ACCESSORIESThe control coils are supplied separately from valve bodies. IM21D – Control coil 12Vac 50/60HzIM21F – Control coil 24Vac 50/60HzIM21H – Control coil 110Vac 50/60HzIM21M – Control coil 230Vac 50/60HzIM22 – Control coil 24Vdc (with coil in d. c. the indicated pressure should be reduced by 60%)IM22A – Control coil 12Vdc (with coil in c. c. the indicated pressure should be reduced by 60%)1578501: Quick connection connector DIN 43650, suitable for all IM2 coils. Cable gland Pg9 (cable diameter 6÷8 mm). Pg11 cable gland thread
-Adjustable cable outlet in 4 positions every 90°.
