EC11-EC14 EXTERNAL PROBESCase in thermoplastic material. Linearized NTC thermistor heat-sensitive element. Bipolar terminal board. G1/4” cable glandEC12-EC15 CONTACT DELIVERY PROBESCase in thermoplastic material. Linearized NTC thermistor heat-sensitive element. Bipolar terminal board. G1/4” cable gland. Plastic clamp that can be reused for fastening to the pipe. EC13-EC16 IMMERSION DELIVERY PROBESCase in thermoplastic material. Linearized NTC thermistor heat-sensitive element. Bipolar terminal board. G1/4” cable gland. Metal protection sheath with G1/2 conical connection for pressure seal. EC17 WELL PROBENTC10K temperature probe. Brass capsule 6x35mm. Double insulation bipolar cable (white-red inside, grey outward) with 2×0,35mm² cable section, length=1,5 meters. Tinned terminals. Insulation: >100mohm @500vca. EC19 FLOOR PROBENTC10K temperature probe. Nylon capsule 7x25mm. Double insulation PVC bipolar cable (white outward) with 2×0,50 mm² or 2×0,35 mm² cable sections, length=3 meters. Tinned terminals. Insulation: >100mohm @500vca. EC21 PROBE FOR SOLAR PANELSStainless steel capsule 3x60mm. Bipolar cable in ptfe. 2×0. 15mm² cable section, length = 1. 5 meters. Terminals: previously insulated leads. Insulation: >20Mohm @500Vac.
