FANTINI COSMI - C04..Y

To control the heating systems -The already preset components are shared as follows:– zone 1 = 1 CH180RFWIFI + 2 O60RF -– zone 2 = 1 CH120RF + 1 O60RF -– zone 3 = 1 CH120RF + 1 O60RF -– zone 4 = 1 CH120RF + 1 O60RF. Remote control through APP Intelliclima+ for Smartphone and Tablet -Expansion possibility for the cooling and dehumidifi cation control system -Expansion possibility up to 8 temperature zones. Electric featuresCH180RFWIFIPower supply 230V-50Hz -Maximum absorbed power: 5 W -Contacts rating 5(3)A 250 Vca -Type of action 1 B. U. (connection micro-switch) -Output type: 1 relay for heating/cooling or humidity systems (3 screw clamps (closed + open) -Software A class -Electric insulation: double insulation -Pulse voltage 4000V. CH120RFWIFIPower supply 230V-50Hz -Maximum absorbed power: 5 W -Contacts rating 5(3)A 250 Vca -Type of action 1 B. U. (connection micro-switch) -Output type: 1 relay for heating/cooling or humidity systems (3 screw clamps (closed + open) -Software A class -Electric insulation: double insulation -Pulse voltage 4000V. O60RFPower supply 2 alkaline batteries (1. 5V AA)Battery life up to 2 years under standard conditions of use
