EVWC8L: 8 inputs/8 outputs connection bar, with timer inputs and safety thermostat
-EVWC8: 8 inputs/8 outputs connection bar, with timer inputs and safety thermostat with circulation pump control. Operating temperature 0°C- 45°C, RH 80% max non-condensing. Storage temperature -10°C – 50°C. Electric featuresPower supply: 230Vac ±10% – 50HzAbsorbed power:– 0. 2VA max for EVWC8L– 2. 5VA max for EVWC8Max applicable load total 3ADelayed fuse protections 3. 15A/T (5×20 mm type)Circulation pump relay contact range 5 (3) A – 250Vac (only for EVWC8)Maximum cable cross-section 2. 5 mm²
