Sensing element with stainless steel diaphragm. Copper bulb and capillary. Copper bulb and capillary,tinned for types C04C2 and C04D2. Base in shock-proof self-extinguishing thermoplastic material V0. Electrical connection output with PVC cable gland. The storage and transport temperature corresponds to the thermostat’s body admissible temperature. Unit weight 0,16 Kg. ACCESSORIESCode 303298LA: cable gland G1/2 for connection output in shock-proof self-extinguishing thermoplastic material V0. Code G23: seal cap Gc 1/2 PN10 bar, without sheath. Code G28: copper sheath Gc 1/2 PN10 bar, length 177mm, supplied with spring to fix the capillary. Electric featuresTwo directions microswitch of instant action with AGcdO contacts. Contact parameters in compliance with EN 60730-1: 15(6)A 250V~ 50Hz.
