Equipped with EC (high efficiency) electrical fans. Forward bladed double inlet fans, installed in Models of size 1600 and greater, already comply with both IE5 and ERP2020 efficiency limits. External structure in galvanized steel sheet
-Thermal and acustic isolation with 23 mm thick polyurethane (40 Kh/m³)
-Motors can be adjusted separately
-Two temperature probes: first probe for the delivery air and second probe for the return air
-Motorized internal by-pass shutter adjustable both manually and automatically
-Pressure-switch to measure the filter stoppage levelControl board set to connect a C02 or humidity probe (optional)
-Equipped electric control board is IP 55 protected
-Centrifugal fans with reverse blades (UVR-HE 500, UVR-HE 700, UVR-HE 1200 Models)
-Centrifugal fans with forward blades (from UVR-HE 1600 to UVR-HE 8500 Models)
-Equipped with an rs485 port that allows:– connection to a single “DeG” remote controller
-– full compatibility with the MODBUS interface
-– up to six base controllers can be linked together using a cascade connection and bemanaged using a single “DeG” remote controller. Filters can be easily inspected and replaced through proper portholes placed on the unit cover
-M6 filter for the external exhaust air
-FT filter for the renewal delivery air
-Aeraulic configuration can be implemented also in the building site
-Remote control unit included
-Mounting brackets included
-Insulator with fireproof sound-absorbing mattress placed on the lower and upper panels
-Condensation collection tray including condensate drain. AP20089, AP20091, AP20093, AP20095 units supplied in double panelingREMOTE CONTROL UNIT:Remote control unit with monochrome display
-Remote control of the UVR-HE units with manual or automatic functioning
-Flush mounting in 3-module boxes (503 type)
-LED light to indicate the filter stoppage status
-Manual and automatic by-pass control
-Control of the two fans in coupled or separate mode
-Detection of the external and internal temperatures
-Fan mode control according to C02 air quality (optional)
-ACCESSORIES:Post-heating hydronic batteries
-Post-cooling hydronic batteries
-Pre and post-heating electric batteries
